Types of Surveys

ALTA/ACSM Survey

An ALTA survey is a property survey based on a set of guidelines jointly established by the American Land Title Association and the American Congress on Surveying and Mapping. The guidelines protect the interest of land buyers, sellers, lenders and title insurance companies relating to commercial property conveyances. A full abstract is researched on the subject parcel and then surveyed to ground and mapped showing all encumbrances that can be graphically plotted.

• EXAMPLE


Boundary Survey

A Boundary survey is often called a Lot survey or Stake survey. The end result is the monumentation or staking of all property corners determined from your legal description of insured property. This could be a lot in a platted subdivision or detached site condominium or a metes and bounds parcel in a rural area commencing or beginning at a government section corner. Each situation will need to be retraced from the original survey.

• EXAMPLE 1


• EXAMPLE 2


Land Surveys

Topographic Mapping

Engineering Design Surveys​

Having worked for both large corporations and small businesses has enabled Mr. McArdle to obtain a vast background of experience within the broad spectrum of commercial and residential surveys relating to ALTA/NSPS Land Title Surveys, Boundary / Lot Surveys, Land Divisions, GPS Surveys, Condominiums / Subdivisions, Topographic Mapping, Engineering Design Surveys, Architectural Surveys, Wetland Mapping, Telecommunication Surveys, GIS Mapping, Construction Staking, F.E.M.A. Flood Elevation Certificates LOMA's, State of Michigan Remonumentation, Engineering Site Plans...etc.

• ALTA/ACSM Land Title Surveys

• Mortgage Surveys
• Boundary Surveys
• Land Divisions
• F.E.M.A. Flood Elevation Certificates
• Engineering Design, Architectural, and Topographic Surveys

​Our Services
